Each range produces excellent results time after time
An intelligent warewashing solution
providing a superior washing performance with reduced costs
Intuitive four colour information
system quickly informs operator of machine status
Quick acting digital thermostats
ensure that temperatures are kept to the absolute optimum
The Optima series provides
control, versatility and power when it’s most needed
Supplied with three dish baskets
Model
OD1450
Cycle time
60 / 120 / 180 / 480 sec
Baskets (x2)
570 x 630 mm
Amps required
Min: 34* Max: 45
Height
1500 mm
Width
1181 mm
Depth
787 mm
Usable wash height
405 mm
Drain ∅
55 mm
Wash tank
60 L
Boiler
24 L
Wash element
7.5 kW
Boiler element
20 kW
Total load
22.2 kW
Detergent dosing
Yes
Rinse aid dosing
Yes
Water connection
3⁄4 BSP
Required water pressure
2-4 bar
Required water flow rate
10 L p/min
Drain pump
Standard
Internal softener**
Optional
Break tank (WRAS)***
Standard
* Dedicated three-phase (3N) machines show the minimum amps per phase based on a boiler priority configuration. The maximum amps per phase is based on the boiler and wash tank elements configured (programmable) to work in tandem.
** Internal water softener is not suitable for hot water above 30˚C. Softening capacity between regenerations is 250 litres @ 300ppm. Where water hardness exceeds 300ppm and the daily wash cycles exceed 80 per day an alternative softener may be required – please contact your supplier for further information.
*** add 25mm to machine depth.
