Each range produces excellent results time after time
Double skinned cabinet and door
improve strength, thermal acoustic insulation and reduce running costs
Rinse and detergent dosing units
and optional water softeners help protect and improve results
Supplied with two dish baskets
Model
SD40
Cycle time
180 sec
Baskets (x2)
400 x 400 mm
Amps required
13 Amps
Model
SD45
Cycle time
180 sec
Baskets (x2)
450 x 450 mm
Amps required
13 Amps
Model
SD50
Cycle time
180 sec
Baskets (x2)
500 x 500 mm
Amps required
13 Amps
Height
690 mm
Height
795 mm
Height
825 mm
Width
475 mm
Width
535 mm
Width
580 mm
Depth
540 mm
Depth
575 mm
Depth
635 mm
Depth – door open
850 mm
Depth – door open
930 mm
Depth – door open
1015 mm
Usable wash height
280 mm
Usable wash height
290 mm
Usable wash height
315 mm
Drain height
120 mm
Drain height
180 mm
Drain height
200 mm
Drain ∅
25 mm
Drain ∅
25 mm
Drain ∅
25 mm
Wash tank
14 L
Wash tank
22 L
Wash tank
26 L
Boiler
2.8 L
Boiler
2.8 L
Boiler
2.8 L
Water usage
2.4 L p/c
Water usage
2.4 L p/c
Water usage
2.4 L p/c
Wash element
1.6 kW
Wash element
2 kW
Wash element
2 kW
Boiler element
2.6 kW
Boiler element
2.6 kW
Boiler element
2.6 kW
Total load
3 kW
Total load
3 kW
Total load
3 kW
Detergent dosing
Yes
Detergent dosing
Yes
Detergent dosing
Yes
Rinse aid dosing
Yes
Rinse aid dosing
Yes
Rinse aid dosing
Yes
Water connection
3⁄4 BSP
Water connection
3⁄4 BSP
Water connection
3⁄4 BSP
Required water pressure
2-4 bar
Required water pressure
2-4 bar
Required water pressure
2-4 bar
Required water flow rate
10 L p/min
Required water flow rate
10 L p/min
Required water flow rate
10 L p/min
Drain pump
Optional
Drain pump
Optional
Drain pump
Optional
Internal softener*
Optional
Internal softener*
Optional
Internal softener*
Optional
Break tank (WRAS)
Optional
Break tank (WRAS)
Optional
Break tank (WRAS)
Optional
* Internal water softener is not suitable for hot water above 30˚C. Softening capacity between regenerations is 250 litres @ 300ppm. Where water hardness exceeds 300ppm and the daily wash cycles exceed 80 per day an alternative softener may be required – please contact your supplier for further information.
Economy
Dishwashers
Economy
Dishwashers
Standard
Dishwashers
Standard Extra Dishwashers
Premium
Dishwashers
Optima
Dishwashers
Fast wash cycle
Heavy duty wash pump
Rinse thermolock
Improved rinse arms
Intuitive, simple controls
EasyClean filters
Chemical auto dosing
Auto drain down
Integral water softener
Hydrodynamic basket slides
Double skinned cabinet
Insulated boiler
Heavy duty heater element
Heavy duty wash pump
Increased usable height
Low volume wash tank
Reduced electrical costs
Counter balanced door
Digital heat sensors
Uprated heating elements
30 amp configuration
Standby mode
Superior peristaltic dosing units
